Datalogic Magellan 2200VSΩ User Manual

Operation and Maintenance
26 Magellan
®
2200VS/2200VS and 2300HS/2300HS
Operational Controls
The function of scanner controls and indicators is listed in Appendix A,
LED/Beeper Indications & Controls
. Turn to that appendix for full
details.
Operational Modes
The scanner features a number of modes that are important to both the
user and the system support personnel. These modes can be combined
into three groups: pre-operational, operational; and additional functions.
The following text describes these modes, what they mean, and how and
when they are seen.
Power-Up/Selftest & Pre-Operation
Pre-Operation describes those steps that must be successfully completed
before the scanner sounds the initial good read tone and illuminates the
LED (lamp) indicating readiness for operation. These steps include
Power-Up Selftest, Error Reporting, and Operational Configuration.
Power-Up/Selftest
Power-Up Selftest begins when power is applied. The scanner’s software
immediately begins the testing sequence to verify that all systems are func-
tioning properly. This routine, which only takes a few seconds, checks all
the functions of the scanner and interface prior to indicating that it is
ready for operation.
NOTE
A tone indicating Selftest is complete is a configurable fea-
ture. See the topic Power-up Beep Control in Chapter 5 of
this manual.
