40 Magellan
®
2200VS/2200VS and 2300HS/2300HS
Integrating the Scanner With Your Host System
Your scanner MUST be equipped with the correct hardware (interface
board, cable, etc.) to properly communicate with your host system. Con-
tact your dealer for information if you have questions about your scanner’s
hardware compatibility.
You may also want to contact the dealer or your system administrator if
you have no record of how your scanner was pre-programmed at the fac-
tory. Scanners are typically programmed with the default settings for spe-
cific interface types; however, your scanner may have been custom
configured with settings that are unique to your company or application.
Once you know the scanner’s current settings, you can determine what
changes will be required to allow communication with your host system
and/or optional features you choose to modify to customize your installa-
tion. After recording the modifications needed, finish reading this chapter,
then turn to the appropriate page and follow the instructions to program
the scanner.
When all scanner features are programmed to your satisfaction, the scan-
ner is ready to be placed into operation.
Customizing Your Scanner’s Operation
Most scanner programming falls within three general categories:
•
General Scanner Features — are features common to all interface
types. Examples include beeper adjustments such as volume and
length, read verification settings, etc.
•
EAS Features — control the settings for interfacing with the
[optional] EAS device.
•
Interface Related Features — are the mandatory settings necessary
to allow communication with your host terminal. Examples of these
settings are: RS-232 baud rate and parity.
CAUTION
It is possible, via programming bar codes, to change the interface type
(for example: from RS-232 to IBM Port 17). Great care should be taken
to select the correct interface type, since you can cause damage to the
scanner and/or POS terminal by attempting to change to an incompati-
ble interface. ALWAYS make interface selections with the host cable
DISCONNECTED.
