Datalogic PowerScan PD9530 Quick Reference Guide

Selecting the Interface Type
Quick Reference Guide 9
Selecting the Interface Type
Upon completing the physical connection between the reader
and its host, proceed directly to Interface Selection below for
information and programming for the interface type the read-
er is connected to (for example: RS-232, Keyboard Wedge,
USB, etc.) and scan the appropriate bar code to select your sys-
tem’s correct interface type.
Interface Selection
All models are multi-interface and support RS-232, USB and
Keyboard Wedge.
Information and programming options for each interface type
are provided in this section. For defaults and additional infor-
mation associated with each interface, proceed to the corre-
sponding chapter in the PowerScan PD9530 PRG.
Configuring the Interface
Scan the appropriate programming bar code to selects the in-
terface type for your system.
Unlike some other programming features and options,
interface selections require that you scan only one
programming bar code label. DO NOT scan an ENTER/
EXIT bar code prior to scanning an interface selection
bar code.
Some interfaces require the scanner to start in the dis-
abled state when powered up. If additional scanner
configuration is desired while in this state, pull the
trigger and hold for 5 seconds. The scanner will change
to a state that allows programming with bar codes.

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
