Datalogic PowerScan PD9530 Quick Reference Guide

LED and Beeper Indications
28 PowerScan™ PD9530
Programming Mode - The following indications ONLY occur
when the reader is in Programming Mode
.
Green Spot
a
flashes momen-
tarily
Upon successful
read of a label, the
software shall turn
the green spot on
for the time speci-
fied by the config-
ured value.
N/A N/A
Image Capture
When ready to cap-
ture image
Blue light flashes 2
times when
updating
N/A
a
Except when in sleep mode or when a Good Read LED Duration other than 00 is selected
INDICATION DESCRIPTION LED BEEPER
Label Program-
ming Mode Entry
A valid programming
label has been scanned.
LED blinks con-
tinuously
Reader sounds
four low fre-
quency beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and cur-
rent volume.
Label Program-
ming Mode
Acceptance of
Partial Label
In cases where multi-
ple labels must be
scanned to program
one feature, this indica-
tion acknowledges
each portion as it is suc-
cessfully scanned.
N/A
Reader sounds
one short beep at
highest fre-
quency and cur-
rent volume.
Label Program-
ming Mode
Acceptance of
Programming
Configuration option(s)
have been successfully
programmed via labels
and the reader has
exited Programming
Mode.
N/A
Reader sounds
one high fre-
quency beep and
4 low frequency
beeps followed
by reset beeps.
Indicator Description LED Beeper

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
