Programming
Quick Reference Guide 19
Programming
The reader is factory-configured with a set of standard default
features. After scanning the interface bar code from the Inter-
faces section, select other options and customize your reader
through use of the programming bar codes available in the
PowerScan PD9530. Check the corresponding features sec-
tion for your interface, and also the Data Editing and Symbol-
ogies chapters of the PRG.
Using Programming Bar Codes
This manual contains bar codes which allow you to reconfig-
ure your reader. Some programming bar code labels, like the
"Reset Default Settings" on page 19, require only the scan of
that single label to enact the change.
Other bar codes require the reader to be placed in Program-
ming Mode prior to scanning them. Scan an ENTER/EXIT
bar code once to enter Programming Mode; scan the desired
parameter settings; scan the ENTER/EXIT bar code again to
accept your changes, which exits Programming Mode and re-
turns the reader to normal operation.
Configure Other Settings
Additional programming bar codes are available in the PRG to
allow for customizing programming features. If your installa-
tion requires different programming than the standard factory
default settings, refer to the PRG.
Resetting Product Defaults
If you aren’t sure what programming options are in your read-
er, or you’ve changed some options and want your custom fac-
tory settings restored, scan the bar code below to reset the
reader to its initial configuration. Reference the PRG for other
options, and a listing of standard factory settings.
Factory defaults are based on the interface type. Be
sure your reader is configured for the correct inter-
face before scanning this label. See "Selecting the
Interface Type" on page 9 for more information.
Reset Default Settings

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
