Datalogic PowerScan PD9530 Quick Reference Guide

LED and Beeper Indications
Quick Reference Guide 27
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indicate
various functions or errors on the reader. An optional “Green
Spot” also performs useful functions. The following tables list
these indications. One exception to the behaviors listed in the
tables is that the reader’s functions are programmable, and so
may or may not be turned on. For example, certain indications
such as the power-up beep can be disabled using programming
bar code labels.
Indicator Description LED Beeper
Power-up Beep
The reader is in the
process of power-
ing-up.
Reader beeps four
times at highest fre-
quency and volume
upon power-up.
Good Read
Beep
A label has been
successfully
scanned by the
reader.
LED behavior for
this indication is
configurable via
the feature “Good
Read: When to
Indicate”
(see the PRG for
information.)
The reader will beep
once at current fre-
quency, volume,
mono/bi-tonal set-
ting and duration
upon a successful
label scan.
ROM Failure
There is an error in
the reader's soft-
ware/programming
Flashes
Reader sounds one
error beep at high-
est volume.
Limited Scan-
ning Label Read
Indicates that a
host connection is
not established.
N/A
Reader 'chirps' six
times at the high-
est frequency and
current volume.
Reader Active
Mode
The reader is active
and ready to scan.
The LED is lit
steadily
a
N/A
Reader
Disabled
The reader has been
disabled by the
host.
The LED blinks
continuously
N/A

Datalogic PowerScan PD9530 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Linear (1D) barcodes supported	-
Standard interfaces	RS-232, USB, Keyboard wedge
Connectivity technology	Wired
Product color	Black, Yellow
International Protection (IP) code	IP65
Input voltage	5 V
Power consumption	350 mA
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	No

Weight and Dimensions

Depth	110 mm
Width	74 mm
Height	212 mm
Weight	330 g
