PDF417 Set Length 1
Specifies one of the bar code lengths for "PDF417 Length Control" on page 211. Length 1
is the minimum label length if in Variable Length Mode, or the first fixed length if in
Fixed Length Mode. Length includes the bar code’s data characters only. Characters can
be set from 0001 to 2,710 characters (pad with zeroes) in increments of 01. Any value
greater than 2,710 will be considered to be 2,710.
See"
Set Length 1" on page 301 for detailed instructions on setting this feature.
PDF417 Set Length 2
This feature specifies one of the bar code lengths for "PDF417 Length Control" on page
211
. Length 2 is the maximum label length if in Variable Length Mode, or the second
fixed length if in Fixed Length Mode. Length includes the bar code’s check, data, and
full-ASCII shift characters. The length does not include start/stop characters. Characters
can be set from 01 to 2,710 characters (pad with zeroes) in increments of 01. Any value
greater than 2,710 will be considered to be 2,710.
See "
Set Length 2" on page 302 for detailed instructions on setting this feature.
Select PDF417 Length 1 Setting
$CP4L1
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar
code at left followed by the digits from the Alphanu-
meric characters in Appendix D, Keypad represent-
ing your desired character(s). End by scanning the
ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL

0001 = Length 1 is 1 Character
Select PDF417 Length 2 Setting
$CP4L2
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar
code at left followed by the digits from the Alphanu-
meric characters in Appendix D, Keypad represent-
ing your desired character(s). End by scanning the
ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL

Length 2 is 2,710 Characters
