TECHNICAL SPECIFICATIONS
312 POWERSCAN™ PD/PM96XX
USER INDICATIONS FOR PM96XX (GUN ONLY)
Table 35 User Indications for PM96XX Gun
STATUS
3GL AND GOOD READ
LED
BATTERY LED BUZZER
Power-up OFF OFF
Rising Beeps’
Sequence
USB Enumeration Phase
250 msec
a
ON ↔ 250 msec OFF
OFF OFF
USB Suspend
Depends on Power Cable and spe-
cific configurations
OFF OFF
Idle OFF OFF OFF
While Reading OFF OFF OFF
Decode Done
Solid ON
Programmable Duration (1 s
default)
OFF Single Beep
Reader Disabled (POS)
Communication with host
not established
100 msec ON
↔ 900 msec OFF
OFF OFF
Firmware Upgrade
250 msec ON
↔ 250 msec OFF
OFF OFF
Host Download
250 msec ON
↔ 250 msec OFF
OFF OFF
Paging Answer
5 cycles:
100 msec ON
↔ 900 msec OFF
OFF
5 Beeps
(when LED ON)
Enter Service Mode No Effect OFF Beeps' Sequence
Label Programming No Effect OFF Beep
ACK Received on
Transmission
OFF OFF
Single Program-
mable Beep
(OFF by default)
ACK NOT Received on
Transmission
OFF OFF Wrong Beep
base station in USB
Suspend
Depends on Power Cable and spe-
cific configurations
OFF OFF
Configuration Alignment
250 msec ON
↔ 250 msec OFF
OFF OFF
Charge in Progress
through microUSB
b
OFF
Blinking: 1 s ON . 1 s OFF
Green (charge = 50% -
99%)
Amber (charge = 1% -
49%)
Red (charge less than 1%)
Reader is unusable until
1% is reached
OFF
Charge Complete through
microUSB
OFF
Solid Green
It goes OFF when
unplugged
OFF
Charge Fault OFF OFF OFF
Charge in Progress
through base station
OFF OFF OFF

Datalogic PowerScan PM96 Series Specifications

General

Brand	Datalogic
Model	PowerScan PM96 Series
Category	Barcode Reader
Language	English
