Datalogic QuickScan QS6500 User Manual

Symbologies
6-92 QuickScan
®
QS6500/QS6500 BT
Interleaved 2 of 5 — continued
Fixed Length Control
One or two fixed lengths may be configured for Interleaved 2 of 5.
Lengths must be even and must include any check digit that may be in
the bar code. If Length 1 or Length 2 are set to non-zero values, the min-
imum and maximum length settings are ignored. To disable fixed
lengths, set Length 1 and Length 2 to a value of 00.
To configure this feature:
1. Determine the length settings needed for Fixed Length 1 and Fixed
Length 2, then reference
Appendix A, ASCII Conversion Chart to
find the corresponding hex values for your chosen lengths. Select-
able lengths are from 0x00 to 0x64 (from 0 to 100 decimal).
2. Scan the START bar code below.
3. Scan either the
Set Fixed Length 1 or Set Fixed Length 2 bar code.
4. Turn to
Appendix B, Alpha-Numeric Pad and scan the hex digits rep-
resenting the desired length. For example, scan 00 to disable the
feature, or 0A to set the length to 10.
5. Scan the SET bar code to accept the digits scanned.
6. Scan the END bar code to exit Programming Mode.

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
