UPC-E
Product Reference Guide 6-11
UPC-E
The following options apply to the UPC-E symbology.
Disable/Enable UPC-E
When disabled, the imager will not read UPC-E bar codes.
Checksum Transmission
Enable this option to transmit the checksum along with UPC-E bar code
data.
Truncate/Expand
None — Turns off the truncation/expansion features listed below.
Truncate NSD — The Number System Digit (NSD) which is usually a
zero (0) in the leading position can be truncated (excluded) from
scanned bar code data.
Expand UPC-E to EAN13 — Adds a leading zero to a UPC-E bar
code which ‘expands’ the data to the EAN-13 data format. Selecting this
feature also changes the symbology ID to match those required for EAN-
13.
Expand to UPC-E to UPC-A — Adds a leading zero to a UPC-E bar
code which ‘expands’ the data to the EAN-13 data format. Selecting this
feature also changes the symbology ID to match those required for EAN-
13.
NOTE
Has no affect on the
Truncate Leading/Ending feature.
To turn it off, set leading/ending values to 00.

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
