Datalogic QuickScan QS6500 User Manual

Interface Features
Product Reference Guide 4-11
RS-232 Interface Features — cont.
Hardware Flow Control
Disable Hardware Control — The imager transmits to the host regardless of
any activity on the CTS line.
Enable CTS Flow Control — The CTS signal controls transmission of data
to the host.
Enable CTS Scan Control — The CTS line must be active for the imager to
read and transmit data. While the CTS line is inactive, the imager
remains in a host-disabled state; following a successful label transmis-
sion, the CTS signal must transition to inactive and then to active to
enable scanning for the next label.
Intercharacter Delay
This delay is inserted after each data character transmitted. If the trans-
mission speed is too high, the system may not be able to receive all char-
acters. You may need to adjust the delay to make the system work
properly.
Software Flow Control
Disables/Enables software control using XON/XOFF characters.

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
