Datalogic QuickScan QS6500 User Manual

Data Editing
5-2 QuickScan
®
QS6500/QS6500 BT
Please Keep In Mind...
• Modifying a message string is not a mandatory requirement. Data
editing is sophisticated feature allowing highly customizable out-
put for advanced users. Factory default settings for data editing is
typically set to NONE.
• A prefix or suffix may be applied to one symbology (reference the
Symbologies chapter for these settings) or across all symbologies
(set via the features in this chapter).
• You can add any prefix or suffix from
Appendix A, ASCII Conversion
Chart
, plus Code I.D/AIM I.D.
• Several entries for several symbologies can be strung together at
one time.
• Enter prefixes and suffixes in the order in which you want them to
appear on the output.
Prefix/Suffix
Up to 22 ASCII characters may be added as a prefix (in a position before
the bar code data) and/or as a suffix (in a position following the bar code
data) as indicated in
Figure 5-2.
Figure 5-2. Prefix and Suffix Positions
SufffixID IDPreamble PostambleBar Code DataCode Length
Insert Groups
00 - 22 Characters (ASCII)
Prefix Symbology

Datalogic QuickScan QS6500 Specifications

General

Scan speed	450 sec/page
Tilt angle range	-60 - 60 °
Maximum scan area	610 mm
Decoding standards	- 1D - Code 16K - EAN/JAN - GS1 DataBar - PDF Models - GS1 DataBar Expanded Stacked - GS1 DataBar Stacked - GS1 DataBar Stacked Omnidirectional - MicroPDF417 - PDF417 - UPC A/E
Dimensions (WxDxH)	165 x 74 x 99 mm
Cable length	2.44 m
Standard interfaces	Keyboard wedge
Input voltage	4.5 - 14 V
Power consumption	300 mA
Certification	RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	181.4 g
