M-Class 47
5.1.4 Printer Options
MODULES
Memory available for user storage of graphics, fonts and label formats. (The
physical presence of the respective memory module must be detected to show the
function selections in the menu system.
PRINT DIRECTORY
Prints a label directory of selected, or of all available modules, the available space
on these modules, the files present, and the type of module and files.
PRINT FILE
The user may select from a list of available files for sample printing.
FORMAT MODULE
The user may select from a list of available modules for formatting – all data will be
erased.
DELETE FILE
The user may select from a list of available files for deleting (protected modules will
not appear). Bytes will not be retrieved until the module that contained the deleted
file is packed.
PACK MODULE
Packing the module removes files marked as deleted and defragments existing file
structures to recover space.
PRESENT SENSOR
Used for on-demand label dispensing, where a printed label blocking the sensor will
inhibit further printing until removed. (The physical presence of the Present Sensor
must be detected to show the ENABLE/DISABLE selections, else NOT
INSTALLED will be displayed momentarily).
MODE
Sets Present Sensor to desired mode of operation.
AUTO
Enables the present sensor when option is installed – present sensor or peel and
present mechanism. Stop location (present distance is automatically set
appropriately for the installed hardware.
ENABLED
Enables the sensor for on-demand printing. Stop location (present distance is
automatically set appropriately for the installed hardware.
DISABLED
Disables the sensor.
RETRACTION DELAY
070 x 10mS (1-255)
Time delay prior to moving label to next start of print in milliseconds.
