Page #27 background imageLoading...
Page #27 background image
Fig.12 Clearance required
AD-0000511-02
C
C
C
800
300
600
800
800
1450
3050
800800
1450
3050
800800
For the dimensions of C:
See
Boiler type C 630 ECO, page 17
5.2.4 Rotating the control panel
The control panel is on the front as standard, but can easily be rotated so
that it is on the short side.
5 Before installation
7600532 - v.11 - 13122018 27
