13.3 Parts list
Tab.41 Casing C 330 ECO
Markers Code no. Description 280 350 430 500 570 650
1001 S103108 Top casing, 5/6/7 sections x x x
1001 S103109 Top casing, 8/9/10 sections x x x
1002 S103111 Top casing front (Large) x x x x x x
1005 S103242 Bracket 44-49 M8 x x x x x x
1006 S103104 Side casing, 5/6/7 sections (Right Angle) x x x
1006 S103102 Side casing, 5/6/7 sections (Left Angle) x x x
1006 S103103 Side casing, 8/9/10 sections (Left Angle) x x x
1006 S103101 Side casing, 8/9/10 sections (Right Angle) x x x
1007 S103098 Side casing, right-hand version x x x x x x
1007 S103097 Side casing, right-hand version, with logo x x x x x x
1007 S103099 Side casing, left-hand version x x x x x x
1007 S103096 Side casing, left-hand version, with logo x x x x x x
1008 S103106 Back casing, right-hand version x x x x x x
1008 S103107 Back casing, left-hand version x x x x x x
1009 S100419 Casing handle x x x x x x
1012 S103152 Frame top, 5/6/7 sections x x x
1012 S103153 Frame top, 8/9/10 sections x x x
1015 S103145 Frame, 8/9/10 sections x x x
1015 S103144 Frame, 5/6/7 sections x x x
1017 S14254 Plate screw 4.2 x 9.5 mm (20 pieces) x x x x x x
1019 S103110 Top casing, middle x x x x x x
1020 S103112 Top casing, front (Small) x x x x x x
1021 S103105 Front casing, instrument panel side x x x x x x
1022 S103154 Bracket support for frame, front x x x x x x
1023 S103155 Bracket support for frame, back x x x x x x
1024 S100570 M5 Bolt x 20 mm (10 pieces) x x x x x x
1025 S103156 Bracket, air box x x x x x x
1027 S103246 Pressure differential switch x x x x x x
1028 S103247
Pressure differential switch securing ring (5
pieces)
x x x x x x
1029 S103251 Ignition transformer x x x x x x
1030 S21473 Locking washer A 4.3 mm (10 pieces) x x x x x x
1031 S103315 Cable retainer (10 pieces) x x x x x x
1032 S103248 M8 Bolt x 10 mm (5 pieces) x x x x x x
1033 S103140 Gasket seal Ø 250 mm (2 pieces) x x x x x x
1034 S103244
Protective plug for the flue gas outlet measuring
point (2 pieces)
x x x x x x
1035 S62288 Grommet for flue gas outlet pipe x x x x x x
1035 S103023 Flue gas thermostat x x x x x x
1036 S103250 M8 Bolt x 35 mm (10 pieces) x x x x x x
1037 S103260 M8 Bolt x 20 mm (10 pieces) x x x x x x
1038 S103249 Washer Ø 8.4 mm (10 pieces) x x x x x x
1039 S103139 Flue gas adapter, 7 + 10 sections x x
1039 S103137 Flue gas adapter, 5 + 8 sections x x
1039 S103138 Flue gas adapter, 6 + 9 sections x x
1040 S103141 Sealing cap (2 pieces) x x x x x x
1041 S101372 Silicon seal, red, Ø 10 mm (5 metres) x x x x x x
1042 S103136 Condensate collector, 8/9/10 sections x x x
1042 S103135 Condensate collector, 5/6/7 sections x x x
13 Spare parts
7600532 - v.11 - 13122018 83
