1. Loosen both the sealing caps on the condensate collector (in front of
and behind the flue gas extraction connection).
2. Thoroughly clean the condensate collector with water. Rinse each
side of the condensate collector for at least 5 minutes with the largest
possible water flow.
3. Refit both sealing caps on the condensate collector.
10.3.10 Clean the siphon
1. Remove the siphon.
2. Clean the siphon with water.
3. Put the siphon back in place.
4. Fill the siphon with water up to the mark via the condensate collector.
Danger
The siphon must always be sufficiently filled with water. This
prevents flue gases from entering the room.
Fig.81 Clean the condensate collector
Fig.82 Cleaning the siphon
10 Maintenance
7600532 - v.11 - 13122018 71
