Removing and Installing Parts 77
PCI Cards
If you are installing or replacing a card, follow the procedures in the next section. If you are
removing but not replacing a card, see "Removing a PCI Card" on page 80".
If you are replacing a card, remove the current driver for the card from the operating system.
If you are installing or replacing a PCI Express card, see "Installing a PCI Express Card" on page 82.
Installing a PCI Card
NOTE: Dell offers an optional customer kit for Audigy II and IEEE 1394 PCI add-in-cards that includes a
front-mounted IEEE 1394 connector.
1
Follow the procedures in "Before You Begin" on page 63.
2
Remove the computer cover (see page 68).
card retention
door
release tabs (2)
filler bracket
alignment guide
alignment bar
