2. Align the notch on the wireless card with the tab on the wireless-card slot and insert the wireless card at an angle into the
wireless-card slot.
3. Align and place the wireless-card bracket on the wireless card.
4. Replace the screw (M2x4) to secure the wireless card to the USB board.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Memory module
Removing the memory module
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image indicates the location of the memory modules and provides a visual representation of the removal
procedure.
Steps
1. Use your fingertips to carefully spread apart the securing-clips on each end of the memory-module slot until the memory
module pops-up.
2. Remove the memory module from the memory-module slot.
NOTE: Repeat step 1 and step 2 to remove the other memory module, if installed on your computer.
Removing and installing components 23
