● View error messages that indicate if problems were encountered during the test
NOTE: Some tests are meant for specific devices and require user interaction. Ensure that you are present in front of the
computer when the diagnostic tests are performed.
For more information, see SupportAssist Pre-Boot System Performance Check.
System diagnostic lights
Battery-status light
Indicates the power and battery-charge status.
Solid white—Power adapter is connected and the battery has more than 5 percent charge.
Amber—Computer is running on battery and the battery has less than 5 percent charge.
Off
● Power adapter is connected, and the battery is fully charged.
● Computer is running on battery, and the battery has more than 5 percent charge.
● Computer is in sleep state, hibernation, or turned off.
The power and battery-status light blinks amber along with beep codes indicating failures.
For example, the power and battery-status light blinks amber two times followed by a pause, and then blinks white three times
followed by a pause. This 2,3 pattern continues until the computer is turned off indicating no memory or RAM is detected.
The following table shows different power and battery-status light patterns and associated problems.
Table 20. LED codes
Diagnostic light
codes
Problem description
1,1 TPM detection failure
1,2 Unrecoverable SPI flash failure
1,5 i-Fuse failure
1,6 EC internal failure
2,1 Processor failure
2,2 System board: BIOS or ROM (Read-Only Memory) failure
2,3 No memory or RAM (Random-Access Memory) detected
2,4 Memory or RAM (Random-Access Memory) failure
2,5 Invalid memory installed
2,6 System board or chipset error
2,7 Display failure - SBIOS message
2,8 Display failure - EC detection of power rail failure
3,1 Coin-cell battery failure
3,2 PCI, video card/chip failure
3,4 Recovery image found but invalid
3,5 Power-rail failure
3,6 System BIOS Flash incomplete
3,7 Management Engine (ME) error
Camera status light: Indicates whether the camera is in use.
● Solid white—Camera is in use.
● Off—Camera is not in use.
Troubleshooting
65
