3. Replace eight screws (M2.5x4) that secure the display-assembly hinges to the palm-rest and keyboard assembly.
4. Turn the display assembly over.
5. Connect the camera cable to the system board.
6. Connect the display cable to the connector on the system board and close the latch to secure the cable.
7. Adhere the tape that secures the display cable to the system board.
8. Route the antenna cables through the routing guides on the fan and adhere the tape that secures the antenna cables to the
system board .
Next steps
1. Install the wireless card.
2. Install the rear cover.
3. Install the base cover.
4. Follow the procedure in After working inside your computer.
Power button
Removing the power button
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the rear cover.
5. Remove the solid-state drive.
6. Remove the wireless card.
7. Remove the memory module.
8. Remove the system board.
NOTE: System board can be removed with the fan and heat-sink assembly, I/O board, and USB board attached.
About this task
The following images indicate the location of the power button and provide a visual representation of the removal procedure.
34
Removing and installing components
