Dell Inspiron 13 5310 User Manual

7. Remove the screw (M2x4) that secures the left-display hinge to the palm-rest and keyboard assembly.
8. Pry open the left-display hinge.
9. Remove the two screws (M2x4) that secure the Type-C port-bracket to the palm-rest and keyboard assembly.
10. Lift the Type-C port-bracket off the palm-rest and keyboard assembly.
11. Pry open the right-display hinge.
12. Lift the display assembly from the palm-rest and keyboard assembly.
CAUTION: To avoid damaging the display, do not slide the palm-rest and keyboard assembly over the display
assembly.
13. After performing the above steps, you are left with the display assembly.
Installing the display assembly
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the display assembly and provides a visual representation of the installation
procedure.
Removing and installing components 37

Dell Inspiron 13 5310 Specifications

General

Display Size	13.3 inches
Graphics	Intel Iris Xe Graphics
Battery	4-Cell, 54 WHr
Wireless	Wi-Fi 6 (802.11ax)
Bluetooth	Bluetooth 5.1
Keyboard	Backlit Keyboard
Processor	11th Gen Intel Core i5/i7
RAM	8GB/16GB LPDDR4x
Storage	256GB/512GB/1TB SSD
Operating System	Windows 10 Home / Windows 10 Pro
Webcam	720p HD
Audio	Stereo speakers with Waves MaxxAudio Pro
Ports	2x Thunderbolt 4, 1x USB 3.2 Gen 1 Type-A, 1x HDMI 1.4, 1x headphone/microphone combo
Resolution	2560 x 1600
Weight	1.25 kg
