5. Align the screw holes on the Type-C port-bracket to the screw holes on the right-display hinge.
6. Replace the two screws (M2x4) that secure the Type-C port-bracket to the palm-rest and keyboard assembly.
7. Connect the display cable to the connector on the system board and close the latch.
8. Adhere the tape that secures the display-cable connector latch to the system board.
9. Place the display-cable bracket over the display-cable connector.
10. Align the screw hole on the display-cable bracket to the screw hole on the system board.
11. Replace the screw (M2x3) that secures the display-cable bracket to the system board.
12. Adhere the tape that secures the display-cable bracket to the system board.
13. Connect the power-button with fingerprint-reader cable to the connector on the system board and close the latch.
14. Connect the coin-cell battery cable to the system board.
15. Connect the I/O-board cable to the connector on the system board and close the latch.
16. Connect the speaker cable to the system board.
17. Connect the touchpad cable to the connector on the system board and close the latch.
18. Connect the keyboard cable to the connector on the system board and close the latch.
19. Connect the keyboard-backlight cable to the connector on the system board and close the latch.
Next steps
1. Install the heat sink.
2. Install the left fan.
3. Install the right fan.
4. Install the wireless card.
5. Install the M.2 2230 solid-state drive or M.2 2280 solid-state drive, whichever applicable.
6. Install the battery.
7. Install the base cover.
8. Follow the procedure in After working inside your computer.
Palm-rest and keyboard assembly
Removing the palm-rest and keyboard assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the wireless card.
5. Remove the left fan.
6. Remove the right fan.
7. Remove the touchpad.
8. Remove the display assembly.
9. Remove the I/O board.
10. Remove the power button.
11. Remove the system board.
NOTE: The system board can be removed with the heat sink and solid-state drives attached.
About this task
The following image(s) indicate the location of the palm-rest and keyboard assembly and provides a visual representation of the
removal procedure.
Removing and installing components
49
