Speakers
Dell™Inspiron™1545ServiceManual
Removing the Speakers
Replacing the Speakers
Removing the Speakers
1. Follow the instructions in Before You Begin.
2. Remove the palm rest (Removing the Palm Rest).
3. Remove the four speaker screws (two on each speaker) from the computer.
4. Disconnect the speaker cable from the connector on the system board.
5. Make note of the speaker cable routing and dislodge the cable from the routing guides.
6. Remove the speakers and the cable.
Replacing the Speakers
1. Place the speakers in position.
2. Route the speaker cable through the routing guides.
3. Connect the speaker cable to the connector on the system board.
4. Replace the four speaker screws (two on each speaker) that secure the speakers.
5. Replace the palm rest (Replacing the Palm Rest).
Back to Contents Page
CAUTION: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
NOTICE: Onlyacertifiedservicetechnicianshouldperformrepairsonyourcomputer.DamageduetoservicingthatisnotauthorizedbyDell™isnot
covered by your warranty.
