Screw list
NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and then
place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is restored when
the component is replaced.
NOTE: Some computers have magnetic surfaces. Ensure that the screws are not left attached to such surface when replacing a
component.
NOTE: Screw color may vary with the conguration ordered.
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Base cover Palm rest and keyboard
assembly
M2x2 2
Base cover Palm rest and keyboard
assembly
M2x4 1
Base cover Palm rest and keyboard
assembly
M2.5x7 6
NOTE: Screw color
may vary depending
on the conguration
ordered.
Battery Palm rest and keyboard
assembly
M2x3 4
Display panel Display back-cover and
antenna assembly
M2x2 4
Fan Palm rest and keyboard
assembly
M2.5x5 3
Hard-drive assembly Palm rest and keyboard
assembly
M2x3 4
Hard-drive bracket Hard drive M3x3 4
Heat sink System board M2x3 3
Hinges Palm rest and keyboard
assembly
M2.5x5 5
Hinge brackets Display back-cover and
antenna assembly
(M2.5x4) 8
5
Screw list 15

Dell Inspiron 3580 Specifications

General

Processor	8th Generation Intel Core i5-8265U
RAM	4GB DDR4
Storage	1TB HDD
Display	15.6-inch FHD (1920 x 1080)
Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Home
Battery	3-cell, 42 WHr integrated battery
Weight	2.2 kg (4.85 lbs)
Ports	2 x USB 3.1 Gen 1
Wireless	802.11ac 1x1 WiFi and Bluetooth
