Removing the power button with ngerprint

reader

WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the

steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside

your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/

regulatory_compliance.

NOTE: Applicable only for computers that are shipped with ngerprint reader.

Prerequisites

1 Remove the optical drive.

2 Remove the base cover.

3 Remove the battery.

4 Remove the solid-state drive/Intel Optane.

5 Remove the fan.

6 Remove the heat sink.

7 Remove the wireless card.

8 Remove the power-button board.

9 Remove the system board.

Procedure

1 Peel the ngerprint reader cable o the palm rest and keyboard assembly.

2 Remove the screw (M2x2) that secures the power button with ngerprint reader to the palm rest and keyboard assembly.

3 Using a plastic scribe, release the ngerprint-reader board from the palm rest and keyboard assembly.

4 Lift the power button with ngerprint reader, along with its cable, o the palm rest and keyboard assembly.

Removing the power button with ngerprint reader 75
