Replacing the optical drive

WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the

steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside

your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/

regulatory_compliance.

Procedure

NOTE: Applicable only for computers that are shipped with optical drive.

1 Align the tabs on the optical-drive bezel with the slots on the optical drive and snap the optical-drive bezel into place.

2 Align the screw holes on the optical-drive bracket with the screw holes on the optical drive.

3 Replace the two screws (M2x3) that secure the optical-drive bracket to the optical drive.

4 Slide the optical-drive assembly into the optical-drive bay.

5 Replace the screw (M2x2) that secures the optical-drive assembly to the base cover.

Replacing the optical drive 19
