Removing the system board

WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the

steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside

your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/

regulatory_compliance.

NOTE: Your computer’s Service Tag is stored in the system board. You must enter the Service Tag in the BIOS setup program

after you replace the system board.

NOTE: Replacing the system board removes any changes you have made to the BIOS using the BIOS setup program. You must

make the appropriate changes again after you replace the system board.

NOTE: Before disconnecting the cables from the system board, note the location of the connectors so that you can reconnect

the cables correctly after you replace the system board.

Prerequisites

1 Remove the optical drive.

2 Remove the base cover.

3 Remove the battery.

4 Remove the memory modules.

5 Remove the wireless card.

6 Remove the solid-state drive/Intel Optane.

7 Remove the fan.

8 Remove the heat sink.

Procedure

1 Disconnect the power-adapter port cable from the system board.

2 Disconnect the speaker cable from the system board.

3 Open the latch and disconnect the keyboard from the system board.

4 Open the latch and disconnect the keyboard back-light cable from the system board.

5 Open the latch and disconnect the touchpad cable from the system board.

6 Open the latch and disconnect the hard-drive cable from the system board.

7 Open the latch and disconnect the I/O board cable from the system board.

8 Open the latch and disconnect the nger-print reader cable from the system board.

9 Lift the latch and disconnect the optical-drive connector-board cable from the system board .

10 Lift the latch and disconnect the optical-drive connector-board cable from the palm rest and keyboard assembly .

11 Lift the optical-drive connector board along with the cable o the palm rest and keyboard assembly (.

12 Open the latch and disconnect the display cable from the system board.

13 Open the latch and disconnect the power-button board cable from the system board.

Removing the system board 69
