Dell Inspiron 7590 User Manual

Table 1. Screw list (continued)
Component Secured to Screw type Quantity Screw image
GPU fan Palm-rest and keyboard
assembly
M2x4 2
M.2 2280 Solid-state
drive
System board M2x4 2
M.2 2230 Solid-state
drive
Palm-rest and keyboard
assembly
M2x4 1
USB Type-C bracket System board M2x4 2
Touchpad bracket Palm-rest and keyboard
assembly
M2x3 3
Touchpad Palm rest and keyboard
assembly
M1.6x2 2
WLAN card bracket WLAN card M2x4 1
System board Palm-rest and keyboard
assembly
M2x4 6
Keyboard bracket Palm rest M1.2x2 39
Base cover
Removing the base cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
About this task
The figure indicates the location of the base cover and provides a visual representation of the removal procedure.
Removing and installing components
11

Dell Inspiron 7590 Specifications

General

Weight	1.87 kg (4.12 lbs)
Processor	Intel Core i5-9300H or i7-9750H
Display	15.6-inch FHD (1920 x 1080) IPS
Graphics	NVIDIA GeForce GTX 1650
Memory	8GB / 16GB DDR4 2666MHz
Storage	256GB / 512GB / 1TB PCIe NVMe SSD
Operating System	Windows 10 Home
Battery	3-Cell 56WHr Integrated
Ports	1 x SD Card Reader, 1 x Headphone/Microphone Combo
Wireless	802.11ac Wi-Fi and Bluetooth
Webcam	720p HD
