Back cover
Removing the back cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
CAUTION: When servicing the computer, place it on an elevated, clean and flat surface. Place the display
flat on the surface with the stand hanging over the edge. It is recommended to remove the stand to avoid
accidental damage to the computer display during servicing.
About this task
The following image indicates the location of the back cover and provides a visual representation of the removal procedure.
Steps
1. Place your palm in the middle of the back cover then pry the back cover from the display-assembly base starting from the
top corners.
2. Remove the back cover from the display-assembly base.
Removing and installing components 13
