Dell Laser Printer 2230d User Manual

Paper sizes supported by the printer
Paper size Dimensions Standard
250-sheet tray
Optional 250-
or 550-sheet
tray
Manual feeder Duplex path
A4 210 x 297 mm
(8.3 x 11.7 in.)
A5
148 x 210 mm
(5.8 x 8.3 in.)
X
A6
1
105 x 148 mm
(4.1 x 5.8 in.)
X X
Executive
184 x 267 mm
(7.3 x 10.5 in.)
X
Folio
216 x 330 mm
(8.5 x 13 in.)
JIS B5 182 x 257 mm
(7.2 x 10.1 in.)
X
Legal
216 x 356 mm
(8.5 x 14 in.)
Letter
216 x 279 mm
(8.5 x 11 in.)
Oficio (Mexico)
2
216 x 340 mm
(8.5 x 13.4 in.)
Statement 140 x 216 mm
(5.5 x 8.5 in.)
X
Universal
3
76.2 x 127 mm
(3 x 5 in.) up to
216 x 356 mm
(8.5 x 14 in.)
X
B5 Envelope
176 x 250 mm
(6.9 x 9.8 in.)
X X X
C5 Envelope
162 x 229 mm
(6.4 x 9 in.)
X X X
DL Envelope 110 x 220 mm
(4.3 x 8.7 in.)
X X X
7 3/4 Envelope
(Monarch)
98 x 191 mm
(3.9 x 7.5 in.)
X X X
9 Envelope
98 x 225 mm
(3.9 x 8.9 in.)
X X X
1
A6 is supported only for grain long papers.
2
This size setting formats the page for 216 x 356 mm (8.5 x 14 in.) unless the size is specified by the software application.
3
If a paper size you want to use is not listed, configure a Universal paper size. For more information, see “Configuring
Universal paper settings” on page 55.
Paper and specialty media guide
68
