Dell Latitude 3400 User Manual

Intel UHD Graphics 620
Table 3. Intel UHD Graphics 620 specifications
Intel UHD Graphics 620
Bus Type Integrated
Memory Type LPDDR3
Graphics Level i3/i5/i7: G T2 (UHD 620)
Estimated Maximum Power Consumption (TDP) 15 W (included in the CPU power)
Overlay Planes Yes
Operating Systems Graphics/ Video API Support DirectX 12 (Windows 10), OpenGL 4.5
Maximum Vertical Refresh Rate Up to 85 Hz depending on resolution
Multiple Display Support
On System: eDP (internal), HDMI
Via Optional USB Type-C Port: VGA, DisplayPort
External Connectors
HDMI 1.4b
USB Type–C port
Nvidia GeForce MX130 equivalent
Table 4. Nvidia GeForce MX130 specifications
Feature Specifications
Graphics memory 2 GB GDDR5
Bus type PCI Express 3.0
Memory Interface GDDR5
Clock Speeds 1122 - 1242 (Boost) MHz
Maximum Color Depth N/A
Maximum Vertical Refresh Rate N/A
Operating Systems Graphics/ Video API Support Windows 10/ DX 12/ OGL4.5
Supported Resolutions and Max Refresh Rates (Hz) N/A
Numbers of Display Support No display output from MX130
Technology and components 13

Dell Latitude 3400 Specifications

General

Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Pro
Processor	Intel Core i3/i5/i7 (8th Gen)
Display	14-inch HD (1366 x 768)
RAM	Up to 32GB DDR4
Battery	3 Cell 42Whr ExpressCharge™ Battery, 4 Cell 56Whr ExpressCharge™ Battery
Ports	2 x USB 3.1, 1 x USB 2.0, HDMI, RJ-45, SD card reader
Wireless	802.11ac Wi-Fi, Bluetooth 5.0
