Dell Latitude C640 User Manual

a.
b.
Lift the Mini PCI card out of its connector.c.
Align the new Mini PCI card with the connector at a 45-degree angle, and press the Mini PCI card into
the connector.
11.
Connect the antenna cable(s) from the Mini PCI card to the antenna connector(s) on the computer.12.
NOTICE: The connectors are keyed for correct insertion; do not force the connections.
1
antenna connectors on card (2)
2
antenna cables (2)
Lower the Mini PCI card toward the inner tabs to approximately a 20-degree angle.13.
Continue lowering the Mini PCI card until it snaps into the inner tabs of the connector.14.
Replace the cover.15.
Replacing the Hard Drive
NOTICE: To prevent data loss, turn off your computer before removing the hard drive. Do not
remove the hard drive while the computer is on, in standby mode, or in hibernate mode.
