Connect the modem cable to the modem.11.
NOTICE: The cable connectors are keyed for correct insertion; do not force the connections.
Align the modem with the screw hole(s), and press the modem into the connector on the system
board.
12.
Install the screw(s) to secure the modem to the system board.13.
Replace the modem cover.14.
Connecting a Television to the Computer
Your computer has an S-video TV-out connector that enables you to connect the computer to a television.
Using a commercially available S-video cable or composite video cable, you can connect the computer to a
television in one of two ways:
NOTE: Diagrams for each connection combination appear at the beginning of each subsection to help
you determine which method you should use.
S-video (for a television with S-video input)
Composite video (for a television with only a composite video input; also uses the Dell-supplied
composite TV-out adapter cable)
The audio connector on the side of the computer enables you to connect the computer to your television or
audio device, using a commercially available audio cable.
When you complete the cable connection, see "Enabling the Display Settings for a Television" to ensure that
the computer recognizes and works properly with the television.
S-Video Connection
