 Mini PCI Card
Dell™Latitude™D410ServiceManual
Removing the Mini PCI Card
Replacing the Mini PCI Card
Removing the Mini PCI Card

1. Follow the instructions in "Preparing to Work Inside the Computer.

2. Remove the center control cover.

3. Remove the keyboard.

4. Remove the metal shield:
a. Loosen the two captive screws that secure the metal shield.
b. Lift the shield on the side near the screw hole, slide the shield tabs out from under the edge of the computer base, and lay the shield aside.

5. If a Mini PCI card is not already installed, go to "Replacing the Mini PCI card."
If you are replacing a Mini PCI card, remove the existing card:
a. Disconnect the antenna cables from the Mini PCI card.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions located in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
NOTICE: To prevent damage to the Mini PCI card connector, do not use tools to spread the securing clips that secure the card.
