 Palm Rest
Dell™Latitude™D410ServiceManual
Removing the Palm Rest
Replacing the Palm Rest
Removing the Palm Rest

1. Follow the instructions in "Preparing to Work Inside the Computer."

2. Remove the center control cover.

3. Remove the keyboard.

4. Remove the internal card with Bluetooth®wireless technology.

5. Remove the display assembly.

6. Turn the computer over and remove the 12 M2.5 x 5-mm screws from the computer base.

7. Turn the computer top side up and remove the five M2.5 x 5-mm screws and the M2 x 3-mm screw from the palm rest.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions located in the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
1
M2.5 x 5-mm screws (12)
