Installing the Front Camera
1. Place the camera module in its slot on the computer.
2. Tighten the screw to secure the camera module to the computer.
3. Connect the camera cable to the connector.
4. Install the:
a) base cover
b) battery
5. Follow the procedures in
After Working Inside Your Computer
.
Removing the Speakers
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the :
a) battery
b) base cover
3. Lift up the coin-cell battery from its slot and un-route its cabling from below the speaker. Disconnect the speaker
connector from the system board.
4. Remove the screws that secure the speakers to the computer.
18
