Installing the Speakers
1. Place the right and the left speakers in their slot.
2. Route the speaker cables on the chassis.
3. Tighten the screws to secure the speakers to the chassis.
4. Place the coin-cell battery in its slot and route the cables.
5. Connect the speaker connector cable to its port on the system board.
6. Install the :
a) base cover
b) battery
7. Follow the procedures in
After Working Inside Your Computer.
Removing the SmartCard Reader
NOTE: The SmarCard reader is an optional component.
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the :
a) battery
b) base cover
3. Remove the screws that secure the SmartCard reader to the system board and lift in an upward direction to remove
it from the computer.
20
