2. Disconnect the battery cable from the connector on the battery.
3. Lift the battery cable off the battery.
Installing the battery cable
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the battery cable and provide a visual representation of the installation procedure.
Steps
1. Align and adhere the battery cable to the battery.
2. Connect the battery cable to the connector on the battery.
Next steps
1. Install the battery.
55
