Dell P24T User Manual

Screw list
Component Secured to Screw type Quantity Screw image
Base cover
assembly
Palm rest and
keyboard
assembly
M2.5x6 9
Battery Palm rest and
keyboard
assembly
M2x3 3
I/O board Base cover M2x3 1
Hard-drive
assembly
Palm rest and
keyboard
assembly
M2x3 3
Hard-drive
bracket
Hard drive M3x3 4
eMMC-card
assembly
Palm rest and
keyboard
assembly
M2x3 3
Power-adapter
port
Palm rest and
keyboard
assembly
M2x3 1
Wireless card Palm rest and
keyboard
assembly
M2x3 1
Display-cable
bracket
System board M2x3 1
Display
assembly
Palm rest and
keyboard
assembly
M2.5x6 2
System board Palm rest and
keyboard
assembly
M2x2 1
11
