Replacing the base cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Replace the I/O board.
CAUTION: To avoid damage to the computer, ensure that the USB and
HDMI port cut-outs on the base-cover assembly is correctly aligned
with the USB and HDMI ports on the palm rest and keyboard assembly.
2 Place the base-cover assembly on the palm rest and keyboard assembly while
aligning the USB and HDMI port cut-out on the base-cover assembly with the
USB and HDMI ports.
3 Slide the tabs on the base-cover assembly into the slots on the palm rest and
keyboard assembly and snap the base-cover assembly into place.
4 Replace the screws that secure the base-cover assembly to the palm rest and
keyboard assembly .
5 Replace the screw cap on the base-cover assembly.
19
