Removing the speaker
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Follow the procedure from step 1 to step 6 in “Removing the base cover”.
2 Remove the battery.
3 Follow the step 1 procedure in “Removing the I/O board”.
Procedure
1 Disconnect the speaker cable from the system board.
2 Remove the coin-cell battery cable from the routing guide on the speaker.
51
