Dell P62F User Manual

Installing the display panel hinges
1. Install the display panel hinges on the display assembly.
2. Install the screws that secure the display panel hinges.
3. Install the:
a. display bezel
b. display assembly
c. system fan
d. LED board
e. WLAN card
f. battery
g. back cover
4. Follow the procedure in After working inside your computer
Removing the camera
1. Follow the procedure in Before working inside your computer.
2. Remove the :
a. back cover
b. battery
c. WLAN card
d. LED board
e. system fan
f. display assembly
g. display bezel
3. To remove the camera:
a. Disconnect the camera connector cable. [1]
b. Lift to remove the camera from the computer. [2]
42

Dell P62F Specifications

General

Model Name	Dell P62F
Category	Laptop
Display	15.6-inch FHD (1920 x 1080)
Operating System	Windows 10
Weight	2.0 kg
Battery	3-cell
