2. Slide the solid-state drive shield into the solid-state drive shield slot. Then align the screw hole on the solid-state drive shield
and solid-state drive to the screw hold on the system board.
NOTE: The 2230 solid-state drive has a unique thermal plate and cannot be interchanged with the 2280 solid-state
drive thermal plate.
3. Replace the screw (M2x3) that secures the solid-state drive to the system board.
Post-requisites
1. Replace the battery.
2. Replace the base cover.
26
Replacing the solid-state drive
