Removing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
Procedure
1. Disconnect the speaker cable from the system board.
2. Remove the four screws (M2x2) that secure the left and right speakers to the palm-rest assembly.
3. Note the speaker-cable routing and peel off the tapes (4) that secure the speaker cable to the keyboard.
4. Lift the left and right speakers, along with their cables, off the palm-rest assembly.
12
Removing the speakers 27
