Removing the palm-rest assembly
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1. Remove the base cover.
2. Remove the battery.
3. Remove the speakers.
4. Remove the display assembly.
5. Remove the headset port.
6. Remove the fans.
7. Remove the system board.
8. Remove the power button with optional fingerprint reader.
9. Remove the keyboard.
Procedure
After performing all the pre-requisites, we are left with the palm-rest assembly.
32
58 Removing the palm-rest assembly
