Dell P84F User Manual

Replacing the solid-state drive
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
CAUTION: Solid-state drives are fragile. Exercise care when handling the solid-state drive.
Procedure to replace M.2 2230 solid-state drive
1. Align the notch on the solid-state drive with the tab on the solid-state drive slot.
2. Slide the solid-state drive firmly into the solid-state drive slot at an angle.
3. Press the other end of the solid-state drive and replace the screw (M2x3) that secures the solid-state drive to the palm-rest
assembly.
4. Slide the solid-state drive bracket firmly into the solid-state drive slot at an angle. Secure the tab on the solid-state drive
slot with the slot on the solid-state drive bracket.
5. Replace the two screws (M2x3) that secure the solid-state drive to the palm-rest assembly.
21
Replacing the solid-state drive 43
