Replacing the power button with fingerprint
reader
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Place the fingerprint-reader cable on the keyboard bracket.
2. Adhere the fingerprint-reader cable to the keyboard bracket.
3. Slide and insert the power button with fingerprint-reader cable on the slot on the keyboard bracket.
4. Follow the procedure from step 3 to step 8 in "Replacing the keyboard".
Post-requisites
1. Replace the system board.
2. Replace the I/O board.
3. Replace the display assembly.
39
82 Replacing the power button with fingerprint reader
