92 Installing System Components
Figure 3-22. Opening and Closing the System
Closing the System
1
Place the cover on the chassis and slide it to the front of the chassis until it
snaps into place. See Figure 3-22.
2
Secure the cover with the securing screw. See Figure 3-22.
Cooling Fans
Removing a Cooling Fan
WARNING: Do not attempt to operate the system without the cooling fans.
WARNING: The cooling fan can continue to spin for some time after the system
has been powered down. Allow time for the fan to stop spinning before removing it
from the system.
1 traction pad 2 system cover
3 cover release latch lock 4 securing screw
book.book Page 92 Thursday, March 4, 2010 4:38 PM
