Installing an internal micro SD card
Installing an internal micro SD card
Prerequisite
Follow the safety guidelines listed in Safety instructions.
NOTE: To use an micro SD card with your system, ensure that the Internal SD Card Port is enabled in System Setup.
Steps
1 Locate the micro SD card connector on the internal dual SD module. Orient the micro SD card appropriately and insert the contact-pin
end of the card into the slot.
NOTE: The slot is keyed to ensure correct insertion of the card.
2 Press the card into the card slot to lock it into place.
NOTE: Temporarily label each SD card with its corresponding slot before removal.
Next step
Follow the procedure listed in After working inside your system.
System board
A system board (also known as the motherboard) is the main printed circuit board found in computers. The system board allows
communication between many of the crucial electronic components of the computer, such as the central processing unit (CPU) and
memory, and also provides connectors for other peripherals. Unlike a backplane, a system board contains signicant number subsystems
such as the processor expansion cards, and other components.
Removing the system board
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Remove the following:
a Processor(s) and heat sink(s)
b Memory modules
c Air shroud
d Drives
e Drive backplane
f Drive cage
g Storage controller card
h PCIe mezzanine card(s)
i IDSDM
j Network Daughter Card (NDC)
k micro SD vFlash card
l Internal USB key
92
Installing and removing system components
