Installing System Components 143
c Disconnect the power cables from any internal optical or tape drives, if
present. See "Removing an Optical or Tape Drive."
d Pull the cables up and away from the notch in the backplane board.
CAUTION: The backplane signal cable can only be disconnected after the
backplane has been removed. Be careful not to pull excessively on the cable
when removing the backplane board. Doing so can damage the cable.
8 Remove the SAS backplane:
a Pull the blue backplane release pin. See Figure 3-25.
b While pulling the release pin, slide the backplane upwards.
c Pull the backplane board away from the front of the system until the
securing slots are free from the tabs in the chassis, and lift the board
from the chassis.
9 Disconnect the backplane signal cable from the backplane. See
Figure 3-25.
book.book Page 143 Tuesday, September 15, 2009 10:08 AM

Dell PowerEdge T610 Specifications

General

Form Factor	5U Tower
Chipset	Intel 5520
Memory Slots	12 DIMM slots
Processor	Up to two Intel Xeon 5500 or 5600 series processors
Memory	1GB/2GB/4GB/8GB/16GB DDR3
Drive Bays	Up to 8 x 3.5" or 16 x 2.5" hot-swap SAS, SATA or SSD
RAID Controller	PERC 6/i, PERC H700, PERC H800
Power Supply	570W or 870W
Network Interface	Embedded Broadcom NetXtreme II 5709c Gigabit Ethernet
Maximum Internal Storage	Up to 16TB
Expansion Slots	6 PCIe slots
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
